• Producent: Yamaha

Amplifier Section Channel 5.1

Rated Output Power (1kHz, 1ch driven) 105W (6ohms, 0.9% THD)

Dynamic Power per Channel (8/6/4/2 ohms) -/110/130/150W

Surround Sound Processing CINEMA DSP Yes

DSP Programs 17

Compressed Music Enhancer Yes

SILENT CINEMA / Virtual CINEMA DSP Yes

Dolby TrueHD Yes

Dolby Digital Plus Yes

Dolby Pro Logic IIx Yes

DTS-HD Master Audio Yes

Audio Features YPAO sound optimization Yes

Adaptive DRC (Dynamic Range Control) Yes

Initial Volume & Maximum Volume Setting Yes

Audio Delay Yes(0-240 ms)

192kHz/24-bit DACs for all channels Yes (Burr Brown)

Video Features HDMI 3D passthrough Yes

HDMI Audio Return Channel Yes

Deep Color/x.v.Color/24Hz Refresh Rate /Auto Lip-Sync Yes

Extensive Connection HDMI Input/Output 4 / 1

HDMI CEC Yes

Dock Port 1 (YDS-12)

Front AV Input Mini Jack/Analog Audio/Composite

Digital Audio Input/Output: Optical 2 / 0

Digital Audio Input/Output: Coaxial 2 / 0

Analog Audio Input/Output 5 (front 1) / 2

Component Video Input/Output 2 / 1

Composite Video Input/Output 5 (front 1) / 1

Preout SW/Surround Back

Headphone Output 1

Tuner Section FM/AM Tuner Yes

User Interface SCENE SCENE (4 sets)

Remote Control Unit Preset

General Standby Power Consumption (IR only) ?0.2W

Auto Power Down Yes

Dimensions (W x H x D) 435x151x364mm

Weight 8.4kg

Audio Technical Specifications Total Harmonic Distortion 0.06%

Signal-to-Noise Ratio 100 dB (Direct, 250 mV)

Package SpeakerChannel 5.1

Speaker System System Frequency Response 30 Hz–25 kHz

Impedance 6 ohms (without subwoofer)

Front Speaker Type Full-range bass-reflex

Driver 7 cm full-range cone

Nominal Input Power 30 W

Maximum Input Power 100 W

Sensitivity 83 dB/2.83 V/1 m

Dimensions (W x H x D) 112 x 176 x 116 mm

Weight 0.59 kg / unit

Center Speaker Type Full-range acoustic suspension

Driver 7cm full-range cone

Nominal Input Power 30 W

Maximum Input Power 100 W

Sensitivity 84 dB/2.83 V/1 m

Dimensions (W x H x D) 276 x 111 x 118 mm

Weight 0.73 kg

Surround Speaker Type Full-range bass-reflex

Driver 7 cm full-range cone

Nominal Input Power 30 W

Maximum Input Power 100 W

Sensitivity 83 dB/2.83 V/1 m

Dimensions (W x H x D) 112 x 176 x 116 mm

Weight 0.59 kg / unit

Subwoofer Type Advanced YST II with Linear Port

Driver 16cm cone

Output Power 50 W (5 ohms, 100 Hz, 10% THD)

Dynamic Power 100 W

Dimensions (W x H x D) 290 x 292 x 327 mm

Weight 8 kg
